Olympus EVIS EXERA III 190 Series Video System

Olympus EVIS EXERA III 190 Series Video System

Imaging System Video Processor

EVIS EXERA III (CV-190)

The EVIS EXERA III CV-190 video system center provides video processing for advanced endoscopy. The system enables easy access to the range of features incorporated into EVIS EXERA III endoscopes. New and improved image processing delivers outstanding image quality, thanks to reduced noise and halation along with improved color contrast for optimal image quality.

Key Benefits

  • Improved image processing: The CV-190 delivers sophisticated image quality via enhanced color reproduction, minimized image noise, and reduced halation.
  • Brighter, more powerful imaging: Narrow Band Imaging (NBI) now delivers significantly increased brightness as well as twice the viewable distance, thanks to an improved lamp design and signal processing.
  • Capture a crisp, clear image the first time: Pre-Freeze dramatically increases the sharpness and clarity of still-image captures.

Main Features:

  1. NBI (Narrow Band Imaging) in EVIS EXERA III 190 Series scopes provides twice the viewable distance of EVIS EXERA II 180 Series scopes and offers significantly brighter images.
  2. CV-190 features the ability to switch the point of focus between ‘near’ and ‘normal’ with the push of a button.
  3. The newly designed, waterproof one-touch connector enables a one-step connection to the light source and does not require a separate scope cable for the video processor.
  4. New and improved image processing delivers sophisticated image quality via enhanced color reproduction, minimized image noise, and reduced halation.
  5. The pre-freeze function selects the clearest still image automatically, saving time.
  6. The CV-190 is compatible with EVIS 100/130/140/150 Series, EVIS EXERA 160 Series, EVIS EVERA II 180 Series, GI/BF/ VISERA Series scopes, and EVIS EXERA III 190 Series.

Specifications:

  • 16:9 and 16:10 outputs for an HDTV monitor are available. The system is compatible with analog, HD-SDI, and DVI output.
  • A link connection to peripheral devices avoids complicated cable connections and accelerates transmission speed.
  • The Olympus documentation system enhances networking expandability.
  • Picture-in-picture and index functions effectively enhance your observation.
  • The system is compatible with portable memory, which is standard for data management; simply connect and upload.
  • The CV-190 supports DV output to compatible documentation devices.

Olympus CLV-190

Main features:

  • NBI (Narrow Band Imaging) in EVIS EXERA III 190 series scopes provides twice the viewable distance of EVIS EXERA II 180 series scopes and offers much greater contrast between blood vessels and mucosa thanks to an improved lamp design and signal processing

  • The newly designed waterproof one-touch connector allows a one-step connection to the light source and does not require a scope cable

  • Considerable reduction in operating noise thanks to a redesigned fan

  • Link connection to peripheral devices avoids complicated cable connections and accelerates transmission speed

  • Automatic light adjustment to achieve ideal illumination for observation with each scope

Olympus 190 Series Video Scope:

Olympus Gastroscope GIF-HQ190

The EVIS EXERA III Videogastroscope GIF-HQ190 revolutionizes routine endoscopy by providing ground-breaking advanced diagnostic features in an easy-to-use routine endoscope.

The EVIS EXERA III Videogastroscope GIF-HQ190 is at the forefront of Olympus endoscopy technology. By uniting features such as Dual Focus and brighter, more powerful Narrow Band Imaging, the GIF-HQ190 offers a truly advanced diagnostic tool packaged in a routine endoscope. In addition to advanced diagnostic features, a range of ergonomic improvements make the endoscope easier to handle throughout the entire endoscope workflow.

Ground-breaking resolving power for efficient diagnosis

OLYMPUS is proud to introduce Dual Focus – a unique optical imaging technology enabling detailed examination of mucosal changes at the touch of a button. With dual focus, Olympus is helping to revolutionize routine endoscopy.

Brighter, more powerful Narrow Band Imaging

Narrow Band Imaging now delivers significantly increased brightness and contrast. Previously widely accepted as a tool for characterisation, the improved brightness may open new possibilities for lesion detection.

Outstanding, true-to-life HD image quality

EVIS EXERA III endoscopes offer true-to-life HD endoscopic images of breath-taking clarity, delivering the optimum support for accurate diagnosis.

Water Jet for a clearer view

The GIF-HQ190 also features an integrated water jet channel helping you keep a clearer view during hemostasis or complex therapeutic procedures.

Olympus Colonoscope CF-HQ-190L

The EVIS EXERA III Videocolonoscope CF-HQ190 revolutionizes routine endoscopy by providing ground-breaking advanced diagnostic features in an easy-to-use routine endoscope. A host of additional features including Responsive Insertion Technology (RIT) ease scope handling assisting in insertion and potentially helping to reduce patient pain. The EVIS EXERA III Videocolonoscope CF-HQ190 is at the forefront of Olympus endoscopy technology. By uniting features such as Dual Focus and brighter, more powerful Narrow Band Imaging, the CF-HQ190 offers a truly advanced diagnostic tool packaged in a routine endoscope. In addition to advanced diagnostic features, a range of ergonomic improvements make the endoscope easier to handle throughout the entire endoscope workflow.

Ground-breaking resolving power for efficient diagnosis

OLYMPUS is proud to introduce DUAL FOCUS – a unique optical imaging technology enabling detailed examination of mucosal changes at the touch of a button. With dual focus, Olympus is helping to revolutionize routine endoscopy.

Brighter, more powerful Narrow Band Imaging

Narrow Band Imaging now delivers significantly increased brightness and contrast. Previously widely accepted as a tool for characterization, the improved brightness may open new possibilities for lesion detection.

Outstanding, true-to-life HD image quality

EVIS EXERA III endoscopes offer true-to-life HD endoscopic images of breath-taking clarity, delivering the optimum support for accurate diagnosis.

Smoother and more comfortable insertion

Responsive Insertion Technologies (RIT) is a host of proprietary insertion tube technologies helping you to further increase caecal intubation rates. The insertion characteristics of endoscopes featuring RIT are significantly improved, meaning you can maneuver the endoscope more easily and your patient experiences less pain.

Olympus Bronchoscope BF-H190

The BF-H190 routine bronchoscope provides high-definition images of unprecedented quality in white light and NBI mode.

This new flagship of Olympus diagnostic bronchoscopes features:

  • Increased upward angulation
  • stunning insertion tube rotation function for precise targeting of EndoTherapy instruments
  • 2.0 mm working channel
  • one-touch connector to the video system

The BF-H190 with incorporated HDTV chip provides brilliant visualization of the bronchial tree, yet its distal end is only 5.5 mm and its insertion tube is a thin 5.1 mm. The 2.0 mm diameter working channel accommodates instruments including lasers, electro-cautery devices, and ultrasonic probes. In NBI mode it is now possible to view twice the visible distance due to the improved performance of the system components. Thus NBI now becomes a really effective observation mode for defining changes in the vascular structure of the mucosa. The rotatable insertion tube with greater upward angulation maximises maneuverability, while features like the waterproof one-touch connector improve endoscopy suite management and help to protect your investment.

Stunning HDTV white light imaging performance and improved NBI

Advancing visualization: The BF-H190 offers HDTV resolution in white light and NBI modes. The system-incorporated pre-freeze function provides sharp still image capture within a fraction of a second.

Insertion tube rotation function and 210° angulation

Advancing maneuverability: The slim insertion tube (5.1 mm diameter, 5.5 mm distal end) has a unique rotation function and upward angulation of 210°. This allows good insertion support and precise targeting during sampling. In addition, it offers additional degrees of freedom to perform the procedure in a more comfortable body position.

The fully waterproof endoscope and one-touch connector

The design of the new waterproof connector allows full submersion without a water-resistant cap and eliminates the associated risk of an expensive repair due to accidental immersion of the endoscope. The one-touch connector links the endoscope to the endoscopy system in a single movement and thus minimises the effort required for set-up prior to, and in-between cases.
